- Frequency Range | 136-174MHz & 400-480MHz
- Memory Channels | 2*128
- Squelch Sensitivity | <0.20µV
- Working Voltage | DC7.4V (Li-ion Battery)
- Other Features:
- LED Flash Light
- Voice Compander
- Scrambler Function
- PTT & ANI ID
- DTMF Encoder & Decoder
What’s In The Box
- Adaptor
- Charger
- Walkie Talkie
- Antenna
- Li-ion Battery
- Belt Clip
Specification
General
| Frequency Range (MHz) |
136-174 MHz & 400-480MHz |
| Operating Temperature |
-20’C~+60’C |
| Frequency Combination |
Phase lock Frequency synthesize |
| Operating Voltage (v) |
7.4 |
| Frequency Stability (ppm) |
±2.5 |
| Operating Temperature (°C) |
-20’C~+60’C |
| Antenna Impedance (Ω) |
50 |
| Dimensions (L x W x H) (with battery, without antenna) (mm) |
115 x 62 x 32 |
| Weight (with antenna & battery) (g) |
130 |
Transmitter
| RF Power Output |
L:1W |
|
H:5W |
| Modulation |
F3E |
| Max.Freq.Deviation |
≤5KHz |
| Remain Wave Radiation |
<-60dB |
| Transmitting Current |
≤1000mA |
Receiver
| Sensitivity |
<0.20µV(12d B SINAD) |
| Selectivity |
<0.20µV |
| Intermodulation |
50dB |
| Rated Audio Power Output |
500mW |
| Receiving Current |
≤100mA |
