What’s In The Box
- Adaptor B-28
- Charger
- Walkie Talkie
- Antenna
- Li-ion Battery
- Hanger
- Belt Clip
Specification
General
| Frequency Range (MHz) | 440-480MHZ |
| Channel Capacity | 16 |
| Channel Spacing (KHz) | 25 / 12.5 |
| Operating Voltage (v) | 7.4 |
| Battery | 2800mAh (Li-ion) |
| Frequency Stability (ppm) | ±2.5 |
| Operating Temperature (°C) | -20~+50 |
| Antenna Impedance (Ω) | 50 |
| Dimensions (L x W x H) (with battery, without antenna) (mm) | 111 x 54 x 34 |
| Weight (with antenna & battery) (g) | 249 |
Transmitter
| RF Power Output | 5W |
| Modulation | 16KΦF3E/8KΦF3E |
| Spurious and Harmonics | ≤-21dBm |
| FM Noise | ≥40dB |
| Audio Distortion | ≤5% |
Receiver
| Sensitivity | 0.25/0.28 µV |
| Selectivity | 55/50dB |
| Intermodulation | 50dB |
| S/N | 45/40dB |
| Rated Audio Power Output | 500mW |
| Rated Audio Distortion | ≤5% |
*All specifications are tested according to TIA/E1A-603, and subject to change without notice due to continuous development.
