General
| Frequency Range |
UHF: 400-480MHz |
| Operating Temperature |
-20°C-+60°C |
| Frequency Combination |
Phase Lock frequency synthesize |
| Frequency Stability |
±2.5ppm |
| Memory Channel |
16 Channels |
| Working voltage |
DC 3.7V |
| Antenna Impedance |
50Ω |
| Operating Mode |
Simplex of co-frequency or alien frequency |
| Dimension |
92mmx52mmx23mm |
| Weight |
150g (Include Battery Pack) |
Transmitter
| RF Power |
3W |
| Modulate Mode (W/N) |
16KΦF3E,11KΦF3E |
| Max. Freq. Deviation (W/N) |
<5K / <2.5KHz |
| Remain Wave Radiation |
<-60dB |
| Transmitting Current |
≤1300mA |
Receiver
| Sensitivity |
<0.25 µV (12dB SINAD) |
| Squelch Sensitivity |
<0.20µV |
| Intermodulation Antijamming |
50dB |
| Audio Power output |
500mW |
| Receiving Current |
≤100mA |
| Squelch Standby |
20mA |
* Saving your presence, no additional notice will be sent if specification changes because of technology-improving.
